Q Series Industrial Robot
RL Robotics Q Series Q6-2000H/2 is a specialised 6-axis industrial robot designed to complex tasks like welding, painting and machine tending in demanding environments. With an impressive 2014mm reach and upto 6 kg payload, this model is optimised for stability and flexibility, making it the ideal choice for large-scale operations in narrow or dense production spacesIts hollow-arm design integrates cables internally to prevent interference, ensuring a streamlined and reliable workflow for multiple applications.
Technical Specifications of Robot
| Mechanism | Vertical multi-joint robot |
| Axis Number | 6 |
| Payload | 6 kg |
| Repeat Positioning | ±0.08 mm |
| Max Armspan | 2014 mm |
| Protection Degree | IP30 |
| Robot Body Weight | 230 kg |
| Temperature | 0 – 45°C |
| Humidity | 20% – 80% RH (No condensation) |
| Vibration | < 4.9 m/s² (0.5G) |
| Power Capacity | 3.4 kVA |
| Cabinet Size | 600 × 480 × 920 mm |
| Cabinet Weight | 95 kg |
| Power Supply | Single-phase AC220V ±10% |
| Installation | Wall / Ceiling |
| Environment Notes |
Avoid flammable, corrosive gases and liquids. Avoid water, oil, dust. Keep away from electrical noise sources. |
What Comes with Your Robot
Each RL Robotics industrial robot is supplied as a complete automation-ready package, including:
Standard Package
● Industrial Robot Arm
● Robot Controller
● Teach Pendant
● Standard cables and accessories
Optional Add-Ons
Positioner / Turntable – Provided as per application requirement.
Integration solution
(Only for Welding)
RL Robotics recommends the BINGO Power Source for robots & cobots, ensuring stable arcs, high repeatability, and reliable automated welding.
Related Industrial Robots
S Siasun Industrial Robot
High-payload robots with extended reach for heavy-duty applications. Built for large-scale and complex automation tasks.
Duco Collabrative Robot
Compact and precise robots ideal for welding and handling tasks. Designed for efficient automation in small to mid-scale setups.
R Series Industrial Robot
Fast and accurate robots built for consistent industrial performance. Perfect for welding and material handling applications.
FAq
What is the Q Series Q6-2000H/2 industrial robot?
The Q Series Q6-2000H/2 is a specialised 6-axis industrial robot optimised for welding, painting, and machine tending. It features a 2014mm reach, 6kg payload, and a unique hollow-arm architecture that integrates cables internally to prevent interference in tight production spaces.
What makes the Q Series different from other industrial robots?
The Q Series stands out with its hollow-arm design that routes cables internally, eliminating cable tangling and interference during operation. This makes it particularly effective for painting and welding applications in narrow or dense production spaces where external cables would cause problems.
Is the Q Series suitable for painting applications?
Yes. The Q Series is specifically designed for painting applications alongside welding and machine tending. Its hollow-arm architecture and stable motion control make it ideal for consistent spray painting operations in automotive and manufacturing environments.
What are the environmental requirements for the Q Series?
The Q Series operates in temperatures from 0°C to 45°C with humidity between 20% and 80% (non-condensing). It should be installed away from flammable or corrosive gases, water, oil, dust, and sources of electrical noise.
What are the key specifications of the Q6-2000H/2?
The Q6-2000H/2 offers 6kg payload, 2014mm reach, ±0.08mm repeatability, 6 axes, IP30 protection, and a robot body weight of 230kg. The controller weighs 95kg with dimensions of 600 × 480 × 920mm, powered by single-phase AC220V.
